**BluePrint Motorsports engines are built for maximum performance and are intended for extreme duty race applications. If this engine is used in a street application our normal 30 month, 50,000-mile warranty applies, if used insanctionedracing no warranty, expressed, or implied.

* Blackout Edition

Overview:

Meet the monster thats powerful enough to dominate the track yet tame enough to rule the streets. Packing a jaw-dropping 815 horsepower and 800 ft-lbs of torque, this 632 cubic inch Pro Series BBC compatible engine is the ultimate blend of raw performance and street-friendly manners. It features a streetable hydraulic roller camshaft, forged pistons, H-beam rods, and a steel crankshaft all anchored in a BluePrint high-strength cast iron block, proudly manufactured and machined in the USA. Topped off with BluePrint aluminum cylinder heads, this is the heart your street beast deserves.

Description:

• Horsepower & Torque: 815 Horsepower / 775 FT. LBS. Torque
• Compression Ratio:11.0:1
• BluePrint Engines Aluminum Heads
• BluePrint Engines Hydraulic Roller Cam
• BluePrint Engines Forged Crank
• BluePrint Engines Forged Pistons

Block:

• BluePrint Engines High Strength Cast Iron Block
• Manufactured and Machined in the USA!
• Tall Deck (Cylinder Deck is Approx .400 taller / Wider than OEM Block)
• Mech Fuel Pump Provision: Yes
• 1-Piece Rear Main Seal
• 4-Bolt Main
• 4.600″ Bore

Rotating Assembly:

• BluePrint Forged Crankshaft
• 4.750″ Stroke
• Forged H-beam 6.635″ Connecting Rods
• Forged Pistons
• Internally Balanced Front and Rear

Cylinder Heads:

• BluePrint Aluminum Cylinder Heads-
• 119cc Chamber
• 2.30″ Intake / 1.88″ Exhaust Valves
• 358cc Intake / 125cc Exhaust Runners
• Cylinder Heads Feature a .300 in. Raised Exhaust Port vs an OEM Casting

Cam Specs:

• Hydraulic Roller
• .698 Intake / .698 Exhaust Lift
• 272 Intake / 282 Exhaust Duration
• @.050-110 Degree Lobe Separation

Also Includes:

• Thermostat and Thermostat Housing
• Pro Billet Distributor –
• Holley Sniper 4500 EFI System
• Harmonic Balancer –
• Spark Plugs –
• Spark Plug Wires
• Intake Manifold
• Timing Cover
• Valve Covers
• Oil Pan

Notes:

• This engine is built and designed to run on 92 octane pump gas for street use only. For racing or extended wide-open throttle use, race fuel (100+ octane) is required.

• BluePrint Motorsports engines are built for maximum performance and are intended for extreme duty applications. Because of the high-stress nature of their use, these engines are sold without any warranty, expressed, or implied.
